1.5/1.8/2.0/2.5/3.0/3.5C series electric forklifts
Product Features
1. Appearance breakthrough
Relying on XCMG's own industrial design center, it breaks through the design limitations of the industrial shape of forklifts in the industry. With a new appearance of XCMG's structural sculptures, it perfectly integrates toughness and smoothness in forklift products.

2. Super performance
A variety of speed mode options, safe mode, economic mode, power mode and strong mode, according to different working conditions, switch at will.
●Two types of cylinder lifting speeds, the safety mode can greatly simplify the operation difficulty and improve the accuracy and safety of the operation when it can meet the slow lifting requirements of special goods;
●Through the precise adjustment of the starting torque and power utility of the product, combined with XCMG's three-stage deceleration integral drive axle, it has achieved a strong climbing degree of 17% and a climbing speed of 5km/h ability.




3. Safe and reliable
●Based on XCMG's proprietary XEC electronic control technology, the product's starting, acceleration, and braking smoothness have been optimized to high standards. Protection of personnel;
The 12 gantry rear inclination angle makes the goods close to the vehicle body during transportation, so as to maintain the stable center of gravity of the vehicle and effectively prevent the goods from accidentally falling during transportation;
Optimized load distribution of front and rear axles, so that when the vehicle is under high load, the rear wheels still have enough grip, and the steering will not slip or become unstable;
The hydraulic system of the XCMG electric forklift adopts the double seal form of conical seal and O-ring seal as standard, which greatly reduces the possibility of leakage of the hydraulic system;
●Integrated buffering function for on-load operation, buffers the goods before they fall to the ground, avoids the impact of the goods and forks on the ground when they fall, and ensures the operation efficiency.




4. Comfortable operation
Equipped with a dual-degree-of-freedom steering mechanism with XCMG independent intellectual property rights, enabling the steering wheel to be adjusted forward and backward and up and down, combined with the standard semi-surrounding luxury seats to provide drivers with different heights comfortable manipulation.
●Based on ergonomics, the position of the handle, the operating force of the pedal and the height of the handle (electronic accelerator) and the position of the brake pedal, the visualization angle of the instrument panel, the position of the rear-view mirror, the position of the rear pillar The three-dimensional space design is optimized for the occlusion of the line of sight and the top view when working at a high position, which greatly improves the comfort.




5. Environmentally friendly and convenient
●The side cover, motor cover, bottom plate, etc. of the forklift are all disassembled without tools, which reduces the tool dependence of maintenance operations;
The battery cover with an opening angle of 95° provides a large safety space for battery maintenance and lifting and replacement;
Independent large-area hydraulic power source maintenance window provides a large operating space for maintenance of hydraulic oil tank, gear pump, and pump motor;
The electrical components such as insurance have been centrally arranged, and the installation positions of the gear pump and pump motor have been properly improved, providing a maintenance position within easy reach for the maintenance of the whole vehicle .

Technical parameters



Load Curve Graph

Features of the electronic control system



Structure of electric counterweights



Technical parameters
